    Electrical Highway BRC Precise Reinforced Mesh Machine

    Ask Lasest Price
    Brand Name : DIXUN
    Model Number : DX-GWC-3000A
    Certification : ISO9001-2008;CE
    Payment Terms : L/C, T/T
    Supply Ability : 5 sets per month
    Delivery Time : 30 working days
    • Product Details
    • Company Profile

    Electrical Highway BRC Precise Reinforced Mesh Machine

    Mesh Size Adjust Highway Construction BRC Reinforcing Mesh Panel Welding Machine


    BRC Reinforcing Mesh Panel Welding Machine Introduction:


    BRC Reinforcing mesh panel welding machine, also called BRC mesh welding machine, Construction mesh welding machine.

    The reinforcement mesh welding machine is used to make steel rebar mesh, road mesh, building construction mesh, etc. With more than 20years experience in design and manufacture, our BRC mesh welding machine is featured by high capacity, easy operation, and precise control.


    BRC Reinforcing Mesh Panel Welding Machine features:


    1. Special pneumatic electrode

    Pneumatic electrodes for welding speed Max. 70 times/min, and adjustable welding pressure for the flat welded panel.


    2. Automatic wire feeding car

    Line wire feeding car for Pre-straighten and pre-cut wires, working faster and saving labor jobs.


    3. Automatic pushing hopper

    Cross-wire pushing hopper with European technology, working faster and continuously.


    4. Automatic pulling mesh

    Servo motor for mesh pulling working with Taiwan Gear rack, cross wire space more precise.


    5. Welding transformer cooling

    Cast water-cooling welding transformer, efficient cooling method, welding current can be adjusted by PLC.


    6. The electrical system

    The electrical system from the international famous brand for precise control and smooth working.

    7. Feeding material

    The warp wire are placed on a corresponding wire penetrating mold by worker, and the weft wire will be automatic falling down one by one ,from the weft wire system.


    8. Welding mesh panel system

    The BRC Reinforcing mesh panel welding machine starts welding and adopts a synchronous control technology, both branch control welding time and welding time are controlled by a Mitsubishi PLC digital programming system, and the mesh opening size can be adjusted only by direct input on a touch screen; and it could be exist different weft distance on one piece of one mesh sheet.


    9. Drawing mesh panel system

    Panasonic ( Japan ) step motor controls the whole automatic mesh panel drawing process until one mesh panel finished, and the automatic mesh connecting and discharging system is started; the welding of the next mesh is started.


    BRC Reinforcing Mesh Panel Welding Machine Parameters:


    Wire diameter5-12mm5-12mm
    Mesh opening size100-300mm100-300mm
    Width of mesh2500mm3000mm
    The number of line wire2632
    Welding speed40-70 times/min40-70 times/min
    Rated electrical power125kva*13125kva*16
    Overall dimension38x4.9x2.2m38x5.4x2.2m
    Line wire formPre-cut wirePre-cut wire
    Cross wire formPre-cut wirePre-cut wire
    Mesh pulling wayControlled by PLC

    Controlled by PLC


    BRC Reinforcing Mesh Panel Welding Machine Applications:


    Application materials : welding machine is good at welding various metal wire : stainless steel wire , low carbon steel wire , round steel bar, ribbed steel bar


    Application mesh panel : welded mesh panel widely used as reinforce mesh panel for building, construction ;railway wire mesh fence, security fence and others.
